rope winch 12000lb from China manufacturer - Ningbo Haochuang Precision Machinery Co.,Ltd.

rope winch 12000lb

Price:	1.0~220.0 USD
Payment Terms:	T/T
Place of Origin:	Zhejiang, China (Mainland)


	Add to My Favorites
HiSupplier Escrow	Share \|

Product Detail

Model No.: SC12.0WX

Production Capacity: 5000pcs/month

Delivery Date: 20 days

Type (Points): 5

OEM No.: SC12.0X

Winch: electric winch

gear ratio: 191:1

Means of Transport: Ocean,Land,Air

Packing: foam package

Material: Nylon

Brand Name: hc winch

Color: BLACK, DARK GREY

clutch: key way cam clutch

gears: 20Cr steel crafted with col...

Water proof winch cold extrusion 20Cr steel gears to meet toughest pulling demands,500A solenoid, 100% function and pulling test

SC12.0WX 12V or 24V

12000LB Heavy Duty Electric Winch

Specification:

Rated line pull: 12000lb (5443kg) single line

Motor: 6.6hp/4.85kw, series wound 12V

Control: Remote switch, 12ft (3.7m) lead

Gear train: 3 stage planetary

Gear reduction ratio: 191:1

Clutch: key way cam

Braking: Automatic load-holding brake

Drum size: Ø2.5″*L8.8″ (Ø63.5mm*L224mm)

Synthetic rope: Ø10.0mm*28m

Fairlead: Polished and Anodized aluminum fairlead

Wireless Remote control: Optional

Battery recommended: 650 CCA minimum for winching

Battery leads: 2 gauge, 72" (1.83m)

Finishing: Black, dark grey coating

Overall dimension (L*W*H): 538*160*214mm

Mounting bolt pattern: 10″*4.5″ (254*114.3mm)

N. W. /G. W.: 27/29KG

Packing: foam package, 1PC/CTN

12V 12000lb Line Speed and Amp Draw ( First Layer)

Line Pull	lbs	0	2000	4000	6000	8000	10000	12000
Line Pull	kg	0	909	1814	2721	3629	4536	5443
Line Speed	ft/min	35.50	20.60	15.19	12	9.84	8.07	7.15
Line Speed	m/min	10.82	6.28	4.63	3.66	3.0	2.46	2.18
Motor	Amos	67	131	198	261	320	389	435

12000lb line pull and cable capacity

Layers of rope		1	2	3	4	5
Rated line pull per layer	lbs	12000	9620	8450	7670	6850
Rated line pull per layer	kg	5443	4364	3833	3479	3107
Cumulative rope capacity	ft	14.76	.30.18	48.23	70.54	91.86
Cumulative rope capacity	m	4.5	9.2	14.7	21.5	28

Key way cam clutch Features

1. Gears are 20Cr steel crafted with cold extrusion and heat treatment, to meet toughest pulling demand.

2. Gear ratio 191:1, high line speed.

3. Rotating to get your winch fully engaged and disengaged both in two directions.

Our company is a professional winch manufacturer for 4x4 electric winches, truck winches, car winches, power winches, jeep winches, ATV trailer winches, boat winches and winch accessories. Our products are produced at a high quality standard to meet your toughest pulling demand and off road activities. All 4wd winch gears are 20CR cold extrusion steel, winches are 100% tested on pulling and function. Welcome you to contact us for business cooperation!
